Save time and create all sheet metal flat pattern DWG / DXF files in one click, directly from the assembly document. Flat Pattern Extractor is ideal for laser cutting and nesting software. The Flat Pattern Extractor will remember all your default settings in term of File format, Layers and geometry conversion. The Flat Pattern Extractor can generate a wide range of file format from older R12 DXF to newest DWG formats that will work with most common postprocessors.

Note: A limitation of 20 files extraction per assembly for the free edition.

Available on the Autodesk Application Exchange

Same as trial with no file count limitations

Available on theAutodesk Application Exchange



Price: 99 $

Copy parameters from a part or assembly document then paste it into another part or assembly document.
   - You can copy Text, Boolean and also Multi Value parameters. You can also include parameter with equation.
   - Paste them into another document (part or assembly) from the same session or from another Inventor session.

- The filter tool will help you to quickly find the parameters you want to copy.

See video demonstration: https://www.youtube.com/watch?v=3wROP3WpLjc

Available on the Autodesk Application Exchange

Same as Full with additionnal tool to include Material name and Gage in filename of extracted dwg or dxf.

Available on demand. Contact me



Price: 399 $



The Where Used Parameter Manager allow users to filter parameter lists based on string search or values. You will also be able to exchange parameters between files by import parameters and their existing formula from one part / assembly to another parts / assembly. You can also use this application to copy parameters lists from Inventor to Excel allowing you to print or save them. You will also be able to quickly create or purge multiples parameters.

See video demonstration : http://www.youtube.com/watch?v=Ki-kSz2cy2Q

Available on Autodesk Application Exchange

The Bar Code Generator allows Inventor users to create and insert one bar code per drawing sheet. (based on standard 128). The professionnal edition allows users to assign an iProperty to it and will update automatically when the drawing is saved.

Available on Autodesk Application Exchange

The script Extractor is normally combined with the Flat pattern extractor and will create your cnc scripts based on a template and insert proper material name, gages, quantity, etc.



The program has a function to merge multiple scripts together allowing you to group multiple products into a single production order for Nesting operation.

Available on demand.
